Dual Smart Dimmer Module

SKU: MTS17D

Dual smart dimming
Seamless integration into any new or existing bell press switches
App Control: Adjust lighting from anywhere using the Major Tech Hub app
Energy Efficient: Precise dimming for LEDs and incandescent lamps (1%–100% range)
Advanced Timing: Supports Countdown, Schedules, Cycle, Random, and Inching Timers
Smart Scheduling: Automate on/off times to match your routine
Smooth Dimming: Flicker-free control in 1% increments for fine-tuned brightness
Custom Automations: Create personalized scenes and brightness settings via the app
Voice Compatible: Works with Alexa and Google Assistant for hands-free control
Reliable Connectivity: Dual Wi-Fi and Bluetooth support with 2.4GHz compatibility
Wi-Fi and Bluetooth
NDIS Category/Support Type: Assistive Technology **(Applicable to Australia)

Quantity

$ 49.00 ex. GST $ 53.90 in. GST

Add to Quote Find a Distributor

Add to wishlist

Details

Enhance your lighting control with the MTS17D 2-Channel Smart Dimmer Module, seamlessly integrated with the Major Tech Hub app for smooth, accurate dimming. Each channel supports up to 125W LED or 200W incandescent loads and can operate in trailing or leading edge mode within a 180-250V AC range, ensuring stable performance. With both 2.4GHz Wi-Fi and Bluetooth, the module guarantees reliable, responsive control, with Bluetooth taking over if Wi-Fi is unavailable. Voice control via Alexa and Google Home adds further convenience. The dual-channel design allows independent

control of two separate lighting circuits in one compact module, reducing installation space and complexity. This makes it perfect for rooms with multiple light sources. Users can also customise lighting automations and schedules across both channels to create layered atmospheres, improve convenience, and optimise energy consumption.

Note:

· The MTS17D supports conventional dimmable lamps or lights (Not intended for smart bulbs).

· Ensure the MTS17D Module is installed by a qualified professional in accordance with local regulations.

· The MTS17D can be used with the Major Tech Hub app and/or manually with bell press switches for app free control.

Specifications:

Function	Range
Rated Frequency	50/60Hz
Rated Max. Load	200W (LED) / 300W (Incandescent)
Rated Max. Load Per Channel	125W-LED / 200W Incandescent
Rated Voltage	180V to 250 V AC
Voltage Range	100 to 264V AC
Wi-Fi Parameter	802.11b/g/n, 2.4GHznetwords only, 5GHz networks not supported
Bluetooth	V5.1GFSK (BT LE)
Voice Control	Alexa& Google Assistant
Dimensions	42 x 42 x 22mm
Housing Material	PC (Flame Retardant VO)
Standards	IEC60669-2-1, IEC60669-1, AS60669.2.1, AS/NZS60669.1
Approvlas	RCM / ICASA / LOA
