The MT965 is a portable vibration meter used for measuring acceleration and velocity. All industrial machinery vibrates therefore knowing the level of vibration is a useful guide for determining the machine condition. Poor balance, misalignment and looseness of the structure will cause the vibration level to increase. This is a sure sign that maintenance is needed. The MT965 has a microprocessor and is the ideal instrument for industrial vibration monitoring.
Vibration Meter
Digital Vibration Meter
Price:
$965.00 ex. GST
$1,061.50 inc. GST
- Measuring acceleration and velocity
- Velocity Range 200mm/s²
- Acceleration Range 0.5 – 199.9 m/s²
- Frequency 10Hz – 1KHz
- Calibration Point Velocity 50mm/s (160Hz)
- Calibration Point Acceleration 50m/s² (160Hz)
- Min / Max
- Separate vibration probe with magnetic base
- RMS and peak measurement
- Microprocessor based
Specifications
Function | Range | Accuracy |
Velocity Range | 0.5 – 199.9mm/s² | |
Acceleration Range | 0.5 – 199.9m/s² | |
Frequency Range | 10Hz – 1KHz | ±(5% +2) 160 Hz, 80Hz |
Calibration Point Velocity | 50mm/s (160Hz) | |
Calibration Point Acceleration | 50m/s² (160Hz) | |
Display | LCD Screen | |
Sample Rate | 1 second | |
Min Max Ave | Yes | |
Overrange Indication | Yes | |
Peak Measurement | Yes | |
Data Hold | Yes | |
Back Light | Yes | |
Enclosure | Over moulded casing | |
Low Battery Indication | Yes | |
Battery | 9V | |
Weight Meter | 274g | |
Weight Probe | 38g | |
Dimensions Meter | 185 x 78 x 38mm | |
Dimensions Probe | 16mm dia x 29mm |
Accessories
Carrying Case
9V Battery
Vibration sensor
Instruction manual
Magnetic base
