SKU: MT310

Socket ELCB Tester


Price:
$41.00 ex. GST
$45.10 inc. GST

  • CAT IV 300V and CAT III 600V
  • Compact, lightweight and easy to use
  • Correct Wiring Indication with neon lights
  • Operates on 230V systems
  • AC Voltage measurement on LCD display
  • Fixed current settings from 10mA to 35mA
  • Separate test button
  • Double injection rubber housing

The MT310 Earth Leakage Tester is a compact, lightweight and easy to use socket and polarity and earth leakage tester that tests 3-wire 230V AC circuits and Earth Leakage Circuit Breakers. A unique feature is the AC Voltage indication on the LCD display. It also features a milli-amp (mA) trip setting with a separate test button. The unit can be set from 10mA, used for testing saturation and to eliminate nuisance tripping, to 35mA. The bright neon indication assists the user in confirming the wiring status of the circuit under test. Simply plug the MT310 into a wall socket and the results are clearly displayed. For additional safety, the MT310 is rated at CAT IV 300V and CAT III 600V.

SKU: MT310 Category:

Specifications

Function Range Accuracy
Voltage measurement 150VAC to 245VAC ± (10%)
Frequency response 50/60Hz
Test current 10, 15, 20, 25, 30, 35mA ± (1.75mA @ 230VAC)
Socket polarity Yes
Enclosure Double Injection moulding
Display LCD
Weight 130g
Dimensions 130 x 69 x 32mm
Safety Specs IEC61010-1 CAT III 600V

Safety Ratings



Accessories

Instruction Manual

Downloads

MT310 Technical Datasheet

MT310 Instruction Manual
