The MT955 capacitance meter is compact in size and lightweight to hold. This meter offers a wide measuring range for all capacitors from 200pF to 20mF. Measurements can be read on the large 2000 count LCD display. This meter includes automatic polarity indication and a zero adjustment for low capacitance range. The MT955 has built-in inputs whereby the capacitors can be inserted directly into the instrument, and for cases where this is not possible due to large capacitors, test leads are supplied.
Capacitance Meters
Digital Capacitance Meter
Price:
$99.00 ex. GST
$108.90 inc. GST
- Capacitance to 20mF
- 0.1pF Resolution
- Automatic polarity indication
- Zero adjustment for low capacitance range
- Easy-to-read 2000 count LCD display
- Low battery indication
Specifications
| Function | Range | Resolution | Accuracy |
| Capacitance | 200pF to 20mF | 0.1pF | ±(0.5% +1 +0.5pF) |
| Overrange Indication | Yes | ||
| “O” Adj. | Yes | ||
| Digital Display | 2000 count LCD | ||
| Enclosure | Rubber holster | ||
| Low Battery Indication | Yes | ||
| Battery | 9V | ||
| Weight | 190g | ||
| Dimensions | 145 x 69 x 38mm | ||
Accessories
9V Battery
HDT1282 Test Leads
Instruction manual
