400A AC/DC Clamp Adaptor
,
SKU: MT783

400A AC/DC Clamp Adaptor

Price:
$155.00 ex. GST
$170.50 inc. GST

  • 400A AC/DC
  • 30mm Jaw Size
  • Non-Contact Voltage Detector
  • 50/60Hz
  • Compatible with any meter capable of 4000 or 6000 count millivolt measurements
  • Can be used with the MT878 as an accessory

The MT783 400A AC/DC clamp-on adaptor designed to be compatible with any instrument capable of 4000 or 6000 count millivolt measurements. The clamp-on adaptor provides an output of 10mV/A on 40A range and 1mV/A on 400A range AC/DC with a frequency response of 50/60Hz. When measuring the current there is no need to break the circuit or affect the insulation. The NCV Non-Contact Voltage is useful for quick check to see if voltage is present.

SKU: MT783 Categories: ,

Specifications

Function Range Accuracy
Jaw Size Ø 30mm Max
DC Voltage 0.1A – 400A ± (2.8% + 0.5A)
AC Voltage 0.1A – 400A ± (2.8% + 0.5A)
NCV 50V to 600V
Frequency 50/60 HZ
Low Battery Indicator Yes
Batteries 2x AAA 1.5V
Weight 173g
Dimensions (LxWxH) 150mm x 58mm x 35mm
