SKU: MTi60

384x288px Thermal Imager

Price:
$9,995.00 ex. GST
$10,994.50 inc. GST

  • 384 x 288 Pixel Thermal Detector
  • 110,592 points real temperature
  • Thermal Temperature Range Low -20 to 150˚C, High 0 to 650˚C
  • 50Hz Image Frequency
  • Laser Distance 30m
  • 3 Area and 2 Line Analysis
  • 3 Manual Spots
  • Hot, Cold and Centre Spot Temperature
  • 3.5″ TFT LCD display, Touch Screen
  • Instant share & save via WiFi to PC, iOS and Android smart devices
  • Colour Pallets include Iron, Rainbow, Grey, Grey Inverted, Brown, Blue/Red, Feather, Zone Alarm
  • Rugged and industrial design casing
  • Easy to use functions via touch screen

The MTi60 High-Performance Thermal Imager with a resolution of 384×288 pix at 50Hz, built-in Laser Distance meter and Wi-Fi ensures that thermal inspections are conducted with greater ease, more effective, and with extreme accuracy. With manual focus, large bright touch screen and easy to access toolbar the user can fine-tune and analyze images quickly and effectively. The touch screen allows the user to manually add up to 3 spot or area measurements, Hot/Cold spot marker that automatically finds the hottest and coldest spots and adjustable zone alarm. It features temperature ranges from -20°C to 650°C, 32X digital zoom, HDMI video output and on-screen adjustable level and span.

This thermal imager is carried in a hard protective carry case which contains a memory card, lithium polymer battery & power supply, and USB cable.

SKU: MTi60 Category:

Specifications

Function Range
Imaging and Optical Data
Field of View 17° x 12.7° / 0.5m
Spatial Resolution (IFOV) 0.77mrad
Thermal Sensitivity/NETD <0.08° at 30°C (86°F)/80mK
Image Range 50Hz
Focus Mode Manual
Zoom 1 -32 x continuous, digital zoom
Focal Length 22mm
Focal Plane Array (FPA) / Spectral Range Uncooled microbolometer / 8-14μm
IR Resolution 384 x 288
Image Presentation
Display Touch screen, 3.5″ LCD, 640 x 480 pixels
Image Modes IR Image, Visual image, picture in picture, Auto Fusion, Laser Distance
Picture in Picture IR area on visual image or visual image on IR
Colour Pallets Iron, Rainbow, Grey, Grey inverted, Brown, Blue red, Hot cold, Feather, Above/Below Alarm, Zone Alarm
Measurement
Temperature Range Low -20°C to 150°C, High 0°C to 650°C
Temperature Accuracy ±2°C or ± 2% of reading (Env temp 10°C – 35°C)
Measurement Analysis
Spot Centre Spot, 3 Manual Spots
Line 2 lines (horizontal or vertical)
Area 3 Area with max/min/average
Automatic Hot/Cold Detection Auto hot or cold markers
Emissivity Correction Variable 0.01 to 1.0, Standard Emissivity Table
Measurement Corrections Emissivity, Reflective temp, Ambient temp, Distance compensation, Relative humidity, Infrared compensation
Laser Distance 0.05 to 30m
Storage
Videos 8Gbytes Micro SD card, 3.4Gb internal EMMC
Videos Format Std MPEG-4, 640 x 480@30fps, on memory card> 60minutes
Videos Storage Mode IR/Visual images: simultaneous storage of IR and visual images
Images Format Std JPEG or .HIR files incl. measurement data, on memory card >6000 pictures
Image Storage Mode IR/Visual images: simultaneous storage of IR and visual images
Digital Camera
Built-in 5 Megapixels
Built-in Digital Lens Data FOV 59°
Data Communications Interfaces
Interfaces USB-mini, HDMI
USB Data transfer between camera and PC, Live video
Video Out HDMI
Wi-Fi 802.11, image transfer and live video
Enclosure Over Moulded casing IP65
Input System DC 5V
Power Source Lithium-ion, 4 hours operating time
Charging System In camera (AC adapter)
Weight 860g
Dimensions 260 x 101 x 120mm

Accessories

Hard Protective Carry Case
Memory Card
Lithium Polymer Battery
Power Supply
USB Cable
Instruction Manual
